Turbidity Removal Water Filtration System
Regular price
$1,959.15
Couldn't load pickup availability
Features
- Timer Control Valves
- Heavy duty composite fiberglass tanks
- High Flow Distributor
- All brass, motor driven control valve with fully adjustable backwash cycles
- Self-adjusting backwash controller
- Flow controller to limit backwash flow
- Engineered for commercial & industrial use
Benefits
- Reduced water consumption
- Engineered for commercial & industrial use
Add-Ons*
- Metered Control Valve
- Backwash bypass
- 3200NT Controller
- NXT Upgrade Controller
- Duplex parallel, twin alternating, triplex (progressive)
- Optional skid mounting for tanks
*If you are interested in our available add-ons, please call to have them added to your system.
| Service Flow Rate ( GPM) | ||||||||
|---|---|---|---|---|---|---|---|---|
| GPM | 15 | 20 | 35 | 60 | 75 | 185 | 200 | 205 |
| Model No. | CQE-CO-02104 | CQE-CO-02105 | CQE-CO-02106 | CQE-CO-02107 | CQE-CO-02108 | CQE-CO-02109 | CQE-CO-02110 | CQE-CO-02111 |
| Electronic Control Valve |
2510 | 2850 | 2850 | 2900 | 2900 | 3900 | 3900 | 3900 |
| Pipe Size | 1" | 1.5" | 1.5" | 2" | 2" | 3" | 3" | 3" |
| PSI Range | 35-60 | 35-60 | 35-60 | 35-60 | 35-60 | 35-60 | 35-60 | 35-60 |
|
Eaglesorb Turbidity Multimedia |
3 ft3 | 4 ft3 | 7 ft3 | 10 ft3 | 15 ft3 | 20 ft3 | 30 ft3 |
40 ft3 |
| Quartz (lbs.) | 30 | 80 | 100 | 200 | 400 | 500 | 700 | 900 |
| Mineral Tank Size (in.) | 14x65 | 16x65 | 21x62 | 24x72 | 30x72 | 36x72 | 42x72 | 48x72 |
| Service flow (gpm) | 15 | 20 | 35 | 60 | 75 | 185 | 200 | 205 |
| Peak flow (gpm) | 22 | 41 | 60 | 95 | 140 | 250 | 270 | 280 |
| Backwash flow (gpm) | 5 | 7 | 12 | 15 | 25 | 35 | 50 | 65 |
| Space Required (in.) (WxDxH) | 15x16x75 | 17x18x75 | 23x24x84 | 24x24x84 | 24x24x95 | 32x32x95 | 40x48x95 | 52x60x95 |
| Consumable |
||||||||
|---|---|---|---|---|---|---|---|---|
| GPM | 15 | 20 | 35 | 60 | 75 | 185 | 200 | 205 |
| Model No. | CQE-CO-02104 | CQE-CO-02105 | CQE-CO-02106 | CQE-CO-02107 | CQE-CO-02108 | CQE-CO-02109 | CQE-CO-02110 | CQE-CO-02111 |
| Eaglesorb Turbidity Removal | 3 ft3 | 4 ft3 | 7 ft3 | 10 ft3 | 15 ft3 | 20 ft3 | 30 ft3 |
40 ft3 |
| Quartz (lbs.) | 30 |
80 |
100 |
200 |
400 |
500 |
700 |
900 |
| Filtration Media Information |
||
|---|---|---|
| Product Data Sheet |
Safety Data Sheet |
|
| Turbidity Removal | Turbidity Removal Product Data Sheet |
Turbidity Removal Safety Data Sheet |
| ERA 6500 & 9500 | ERA 6500 & 9500 Product Data Sheet |
ERA 6500 & 9500 Safety Data Sheet |
| Ion Exchange | Ion Exchange Resin Product Data Sheet |
Ion Exchange Resin Safety Data Sheet |
| Installation Instructions |
||||||||
|---|---|---|---|---|---|---|---|---|
| SYS. INSTALLATION & OPERATION GUIDE |
||||||||
| GPM | 15 | 20 | 35 | 60 | 75 | 185 | 200 | 205 |
| Model No. | CQE-CO-02104 | CQE-CO-02060 | CQE-CO-02061 | CQE-CO-02062 | CQE-CO-02063 | CQE-CO-02064 | CQE-CO-02065 | CQE-CO-02066 |
| Electronic Valve |
2510 Control Head Manual |
2815 Control Head Manual |
2815 Control Head Manual |
2900 Control Head Manual |
2900 Control Head Manual |
3900 Control Head Manual |
3900 Control Head Manual |
3900 Control Head Manual |
| Mechanical Upflow Valve | 1" |
1.5" |
1.5" |
1.5" |
2" |
N/A |
N/A |
N/A |
|
Mechanical Down Flow/ Backwashable Valve |
1" | 1.5" | 1.5" | 1.5" | 2" | N/A | N/A | N/A |
| Schematics | Review | Review | Review | Review | Review | Review | Review | Review |
| Schematic Samples | ||
|---|---|---|
|
Single Standard Configuration |
Double Standard Configuration |
Triple Standard Configuration |
Turbidity Removal Product Data Sheet
Turbidity Removal Safety Data Sheet
