SMART Under Sink Water Filter System
Couldn't load pickup availability
Benefits
Recommended Leak Detector/Flood-Prevention Valve : Due to numerous unpredictable circumstances including installation errors, flood damage is subject to occur without a leak-detector valve. Our recommended leak detector/flood-prevention valve will allow the water system to be flood-proof.
Our SMART Under Sink Water Filter System reduces or removes contaminants such as chlorine & heavy metals from tap water to offer the freshest taste to you. The perfect solution for any household, this water filter system is quick and easy to install and use, attractive, and convenient.
This solid state water filter uses the latest technologies that blend the adsorption capabilities of coconut shell activated carbon with Eagle Redox Alloy® and more.
- Installs neatly under the sink.
- Comes with a beautiful faucet and all necessary installation hardware.
- Conveniently provides 10,000 gallons of water (1-3 years, or when the flow of water will automatically either stop or slow down greatly.)
- Great for homes, apartments or office use.
When considering installation, if current under sink plumbing is hard copper tubing the saddle valve would be used; for flex tubing, the T-valve would be required. While ordering a prompt will require that an installation valve is specified in order to progress through the order entry screen.
SMART Water Filter Cartridge
Water flows through a bed of media made of a special high-purity alloy blend of two dissimilar metals - copper and zinc (ERA-6500, ERA-9500). ERA-6500 and ERA-9500 are major advancements in water treatment technology that works on the electrochemical and spontaneous-oxidation-reduction (Eagle Redox Alloy®) principles. Chlorine is instantaneously and almost inexhaustibly oxidized.
Water flows through ion exchange resins, reducing heavy metals such as lead, copper, aluminum, and water hardness.
Water flows through granulated activated carbon (GAC). GAC is universally recognized and widely used as an effective adsorbent for a wide variety of organic contaminants, such as chlorine, chemicals linked to cancer (THM's, benzene) pesticides, herbicides, insecticides, volatile organic compounds (VOC's), PCB's, MTBE's and hundreds of other chemical contaminants that may be present in water causing bad taste and odors in your drinking water.
All Crystal Quest® GAC is a mixed blend of coconut shell and catalytic GAC to address both chlorine, chloramines and these byproducts.
Carbon Block Water Filter Cartridge
Water travels through a 5-micron solid carbon cartridge for removing volatile organic carbon compounds (VOC's), insecticides, pesticides and industrial solvents and traps particles larger than 5 microns including sediment, silt, sand, and dirt.
Sediment Water Filter Cartridge
Water travels through a sediment filter cartridge that removes sediment, silt, sand, and dirt. This also helps to extend the life of the water filter system.
Dimensions
| Dimensions | |
|---|---|
| Single | 5"L x 14"H x 5"W |
| Double | 10"L x 14"H x 5"W |
| Triple | 15"L x 14"H x 5"W |
Operating Specs
| Connection Size | 1/4" |
| Min Operating Pressure | 20 psi (pounds per sq. in.) |
| Max Operating Pressure | 60 psi (pounds per sq. in.) |
| Min Operating Temperature | 40° F |
| Max Operating Temperature | 90° F |
| Max Flow Rate | 0.5 gpm (gallons per minute) |
Replacement Cartridges
Which cartridges are in my system?
| Product Name | Single | Double | Triple |
|---|---|---|---|
| Sediment Filter Cartridge (2-7/8" x9-3/4”) CQE-RC-04001 | No | No | Yes |
| SMART Filter Cartridge (2-7/8" x9-3/4”) CQE-RC-04002 | Yes | Yes | Yes |
| Carbon Block Filter Cartridge (2-7/8" x9-3/4”) CQE-RC-04000 | No | Yes | Yes |
Product Manual
