Lead Removal Water Filtration System

SKU: CQE-CO-02174
Regular price $2,921.52
Flow Rate
Rendering loop-subscriptions

Features

  • Timer Control Valves
  • Heavy-Duty Composite Fiberglass Tanks
  • Heavy-Duty Brine Tank
  • High Flow Distributor
  • All brass, motor driven control valve with fully adjustable regeneration cycles
  • Self-adjusting backwash controller
  • Flow controller to limit backwash flow
  • Engineered for commercial & industrial use

Benefits

  • Reduced water consumption
  • Reduced salt usage
  • Engineered for commercial & industrial use

Add-Ons*

  • Metered Control Valve
  • Metered to regenerate based on demand
  • Backwash or regeneration bypass
  • 3200NT Controller
  • No Hard Water Bypass
  • NXT Upgrade Controller
  • Duplex parallel, twin alternating, triplex (progressive)
  • Optional skid mounting for tanks

*If you are interested in our available Options, please call to have them added to your system.

Lead (Pb) is a soft and heavy metal used in a surprisingly wide range of industrial applications and processes. It is a highly poisonous neurotoxin that can accumulate in both soft tissue and bone, leading to brain and nervous system disorders. Exposure to lead is especially dangerous for young and developing children. Most commonly it is introduced to the human body by ingestion of contaminated water and food, although it can be introduced through inhalation and direct contact as well.

How It Works

Our SMART Multimedia is a special house blend of 2 types of coconut-shell GAC (including Catalytic) with 2 types of Eagle Redox Alloys® (9500 & 6500) and anion exchange resin. This blend effectively reduces and removes heavy metals, chlorine & chloramine, pesticides & herbicides, pharmaceutical by-products & other inorganic substances such as petroleum byproducts. This blend will help the oxidation process of the lead for easier removal. To read about the ERA® Oxidation/Reduction Process, click here. In addition to the oxidation process, we also include the Crystal Quest Eagle Softener Resin which is a strong acid cation exchange resin. It should be regenerated with either potassium chloride or sodium chloride. Typically, it requires about 10% more salt to regenerate with potassium chloride salt when compared to sodium chloride salt. The advantage of potassium salt is that it does not contribute to a high sodium diet and the backwash can be discharged onto a lawn or garden. Sodium chloride salt will kill plants, so it must be discharged into a sewer system. Salt and Iron Out remove iron levels up to 4 ppm. Media can be regenerated at 8, 12 and 15 lbs. per ft3 salt dosages.

    Service Flow Rate ( GPM)
    GPM 7
    10
    20-22
    30
    40
    80
    100
    140
    Model No. CQE-CO-02174 CQE-CO-02175 CQE-CO-02176 CQE-CO-02177 CQE-CO-02178 CQE-CO-02179 CQE-CO-02180 CQE-CO-02181
    Electronic Control Valve 2510 2850 2900 2900 3150 3900 3900 3900
    Pipe Size 1.5" 2" 2" 2" 2" 3" 3" 3"
    PSI Range 35-60 35-60 35-60 35-60 35-60 35-60 35-60 35-60
    Smart Multimedia  ft3  ft3  ft3 10  ft3 15  ft3 20  ft3 30  ft3 40 ft3
    Quartz (lbs.) 30 80 100 200 400 500 700 900
    Mineral Tank Size (in.) 14x65 16x65 21x62 24x72 30x72 36x72 42x72 48x72
    Brine Tank Size (in.) 24x41 24x41 24x50 30x50 39x48 39x60 42x60 50x60
    Service flow (gpm) 7-9 10-12 20-22 30-35 40-45 80-85 100-110 140-150
    Peak flow (gpm) 22 41 60 95 140 250 270 360
    Backwash flow (gpm) 5 7 12 15 25 35 50 65
    Space Required (in.) (WxDxH) 48x26x73 50x26x84 56x26x75 64x32x87 79x41x90 85x41x90 94x44x90 114x50x96
    15 20 35 60 75 185 200 280
    Service Flow Rates (GPM)



    Consumables
    GPM 7
    10
    20-22
    30
    40
    80
    100
    140
    Model No. CQE-CO-02174 CQE-CO-02175 CQE-CO-02176 CQE-CO-02177 CQE-CO-02178 CQE-CO-02179 CQE-CO-02180 CQE-CO-02181
    Lead Media  ft3  ft3  ft3 10  ft3 15  ft3 20  ft3 30  ft3 40 ft3
    Quartz (lbs.) 30 80 100 200 400 500 700 900






    Features

    • Timer Control Valves
    • Heavy-Duty Composite Fiberglass Tanks
    • Heavy-Duty Brine Tank
    • High Flow Distributor
    • All brass, motor driven control valve with fully adjustable regeneration cycles
    • Self-adjusting backwash controller
    • Flow controller to limit backwash flow
    • Engineered for commercial & industrial use

    Benefits

    • Reduced water consumption
    • Reduced salt usage
    • Engineered for commercial & industrial use

    Add-Ons*

    • Metered Control Valve
    • Metered to regenerate based on demand
    • Backwash or regeneration bypass
    • 3200NT Controller
    • No Hard Water Bypass
    • NXT Upgrade Controller
    • Duplex parallel, twin alternating, triplex (progressive)
    • Optional skid mounting for tanks

    *If you are interested in our available Options, please call to have them added to your system.

    Lead (Pb) is a soft and heavy metal used in a surprisingly wide range of industrial applications and processes. It is a highly poisonous neurotoxin that can accumulate in both soft tissue and bone, leading to brain and nervous system disorders. Exposure to lead is especially dangerous for young and developing children. Most commonly it is introduced to the human body by ingestion of contaminated water and food, although it can be introduced through inhalation and direct contact as well.

    How It Works

    Our SMART Multimedia is a special house blend of 2 types of coconut-shell GAC (including Catalytic) with 2 types of Eagle Redox Alloys® (9500 & 6500) and anion exchange resin. This blend effectively reduces and removes heavy metals, chlorine & chloramine, pesticides & herbicides, pharmaceutical by-products & other inorganic substances such as petroleum byproducts. This blend will help the oxidation process of the lead for easier removal. To read about the ERA® Oxidation/Reduction Process, click here. In addition to the oxidation process, we also include the Crystal Quest Eagle Softener Resin which is a strong acid cation exchange resin. It should be regenerated with either potassium chloride or sodium chloride. Typically, it requires about 10% more salt to regenerate with potassium chloride salt when compared to sodium chloride salt. The advantage of potassium salt is that it does not contribute to a high sodium diet and the backwash can be discharged onto a lawn or garden. Sodium chloride salt will kill plants, so it must be discharged into a sewer system. Salt and Iron Out remove iron levels up to 4 ppm. Media can be regenerated at 8, 12 and 15 lbs. per ft3 salt dosages.

      Service Flow Rate ( GPM)
      GPM 7
      10
      20-22
      30
      40
      80
      100
      140
      Model No. CQE-CO-02174 CQE-CO-02175 CQE-CO-02176 CQE-CO-02177 CQE-CO-02178 CQE-CO-02179 CQE-CO-02180 CQE-CO-02181
      Electronic Control Valve 2510 2850 2900 2900 3150 3900 3900 3900
      Pipe Size 1.5" 2" 2" 2" 2" 3" 3" 3"
      PSI Range 35-60 35-60 35-60 35-60 35-60 35-60 35-60 35-60
      Smart Multimedia  ft3  ft3  ft3 10  ft3 15  ft3 20  ft3 30  ft3 40 ft3
      Quartz (lbs.) 30 80 100 200 400 500 700 900
      Mineral Tank Size (in.) 14x65 16x65 21x62 24x72 30x72 36x72 42x72 48x72
      Brine Tank Size (in.) 24x41 24x41 24x50 30x50 39x48 39x60 42x60 50x60
      Service flow (gpm) 7-9 10-12 20-22 30-35 40-45 80-85 100-110 140-150
      Peak flow (gpm) 22 41 60 95 140 250 270 360
      Backwash flow (gpm) 5 7 12 15 25 35 50 65
      Space Required (in.) (WxDxH) 48x26x73 50x26x84 56x26x75 64x32x87 79x41x90 85x41x90 94x44x90 114x50x96
      15 20 35 60 75 185 200 280
      Service Flow Rates (GPM)



      Consumables
      GPM 7
      10
      20-22
      30
      40
      80
      100
      140
      Model No. CQE-CO-02174 CQE-CO-02175 CQE-CO-02176 CQE-CO-02177 CQE-CO-02178 CQE-CO-02179 CQE-CO-02180 CQE-CO-02181
      Lead Media  ft3  ft3  ft3 10  ft3 15  ft3 20  ft3 30  ft3 40 ft3
      Quartz (lbs.) 30 80 100 200 400 500 700 900
