Metal Removal Whole House Water Filter
Select product option
Remove Iron, Manganese, and Hydrogen Sulfide from Your Drinking Water
Iron (Fe ) & Manganese (Mn) are metallic elements present in many types of rock. Most groundwater contains some iron and manganese which naturally leaches from rocks and soils. Excess amounts in drinking water can cause discolored water, bad bitter tastes, and rust flakes in the water, as well as rusty-brown stains or black specks on fixtures and laundry. Excess amounts may also affect the taste of beverages and can build up deposits in pipes, heaters or pressure tanks. Hydrogen sulfide (H 2 S), which causes a “rotten egg” odor, can also be released from the soil by the same conditions (low dissolved oxygen and low pH) that cause iron and manganese to dissolve in water. Hydrogen sulfide is frequently found in water with excessive iron and manganese.
Water flows through a 20” sediment cartridge that removes sediment, silt, sand, and dirt.
Water flows through a 20" solid carbon cartridge for removing volatile organic carbon compounds (VOC's), & any remaining insecticides, pesticides and industrial solvents.
Metal Removal Water Filter
Water flows through an iron, manganese, and hydrogen sulfide-reducing mineral tank. In addition, we add our media, ERA® 6500 & 9500 to prevent bacteria growth.
SMART Water Filter (optional)
Water flows through our SMART special house blend of 2 types of coconut-shell GAC (including Catalytic) with 2 types of Eagle Redox Alloys® (9500 & 6500) & anion exchange resin. This blend effectively reduces & removes heavy metals, chlorine & chloramine, pesticides & herbicides, pharmaceutical by-products & other inorganic substances such as petroleum byproducts. Ceramic and Tourmaline balls to enhance the water and maintain a more alkaline pH. To read about how GAC's work, click here. To read about the ERA® Oxidation/Reduction Process, click here.
Water Softener (optional)
Water flows through an ion exchange resin and brine water conditioner.
Media may increase hardness in the water which is why a water softener is recommended. Water is hard when it contains minerals like calcium and magnesium. You may see staining on your sinks, tubs, showers, and clothing. You may also notice less lather from your shampoos and soaps and even a feeling of film on your skin. All these are symptoms of the need for softened water. Hard water also causes a higher risk of limescale deposits in household water systems. The negative effect of limescale buildup is that pipes are blocked and the efficiency of hot boilers and tanks is reduced. This increases the cost of domestic water heating by about fifteen to twenty percent. Another negative effect of limescale is that it has damaging effects on household machinery, such as laundry machines. Water softening means expanding the lifespan of household machines, and the lifespan of pipelines. It also contributes to the improved working and longer lifespan of solar heating systems, air conditioning units and many other water-based applications.
Additional Product Options
- Leak Detector Valve: Used to detect a water leak within a water filter system and shuts down the water supply to prevent flooding.
- 12 GPM UltraViolet Water Sterilizer: Specifically designed to meet the demanding microorganism control concern. These microorganisms can range from bacteria and viruses to algae and protozoa. A major advantage of UV treatment is that it is capable of disinfecting water faster than chlorine without cumbersome retention tanks and harmful chemicals to your drinking water.
Important to Know
Pinholes or rust may occur on stainless steel tanks in environments with high humidity, when salt is present or if condensation remains on tank without being routinely wiped down. If your system will be exposed to one of these factors or you are unable to perform the needed maintenance, we recommend a fiberglass tank.
|Filter Media Volume||1.5 cubic feet||2.0 cubic feet|
|Service Flow (GPM)||9-11||10-13|
|Tank Dimensions||10" x 54"||12" x 52"|
|Material||Stainless Steel or Fiberglass||Stainless Steel or Fiberglass|
|Brine Tank Dimensions*||18" x 33"||18" x 33"|
*When you have a softener selected
|Eaglesorb Water Softeners||CQE-RM-05002|
|Sediment Cartridge (2-7/8"x20")||CQE-RC-04015|
|Carbon Block Filter Cartridge (2-7/8"x20")||CQE-RC-04014|
Eagle Redox Alloy 6500 & 9500 Saftey Data Sheet
Iron Oxide 1 S (Green Sand) Safety Data Sheet
Iron Oxide 1 S Product Data Sheet
Iron Oxide II Pyrolox Product Data Sheet
Iron Oxide II Pyrolox Safety Data Sheet
2.0 Turbidity Iron CN Schematic
2.0 Turbidity Iron SMART Schematic
1.5 Iron SMART Antiscale Schematic
2.0 Turbidity Iron CN Schematic
CL Iron Softener Lead Arsenic Schematic
Iron Softener Fluoride SMART Schematic
