$231.57 Regular price $249.00 SKU CQE-RC-04109

Save $17.43 compared with one-time purchase

2.5" x 40" Freshwater Reverse Osmosis Membrane

$231.57 Regular price $249.00

Restores production and clean taste in any RO system built for standard 2.5 x 40 inch (2540) membranes, including mid-size Crystal Quest whole house and...

Quantity, Single
Purchase option
$249.00

  • Shop Pay
  • Apple Pay
  • Google Pay
  • Visa
  • Mastercard
  • American Express
Shipping

Free shipping on orders over $150

Residential addresses in the lower 48 US states. Excludes business addresses, commercial and industrial systems (which ship by freight), and filter media sold by the bag or cubic foot.

This item ships free

Order by 3:00 PM Eastern on a business day and most filters, cartridges and smaller items leave our facility that same day. Standard residential systems ship within 1 to 2 business days, and whole house, custom and specialty systems typically within 3. So far in 2026, 95% of our orders have shipped within one business day and 99% within five (based on an internal review of our order records).

Once shipped, standard delivery typically arrives in 3 days to the Southeast, Northeast and Southwest, and in 4 days to the Midwest and the West. Need it sooner? UPS 2nd Day Air and Next Day Air are available at checkout for eligible products. Systems that ship by freight can take longer and may need a delivery appointment.

60-day returns

In its sealed factory packaging, this item can be returned within 60 days of delivery. Once it has been opened or used, it cannot be returned. You pay shipping both ways, and every return needs a return approval number from us first.

Lifetime support

Our team answers questions about products, orders, installation, troubleshooting and replacement parts.

Phone: (770) 951-5600 or (800) 934-0051

Email: help@crystalquest.com. Typical responses within 24 hours (M-F).

Live chat during business hours

Hours: Monday to Friday, 9:00 AM to 5:00 PM Eastern. We observe U.S. federal holidays.

2.5" x 40" Freshwater Reverse Osmosis Membrane, long light green fiberglass element with cream end cap, angled view

How do I install it?

  • Size: this is a 2.5" x 40" (2540) element. Shorter 2.5" x 14" and 2.5" x 21" elements are not interchangeable with it.
  • Count: Whole House RO 750 GPD uses one, 1,500 GPD uses two and 2,500 GPD uses three. Replace the full set together.
  • Class: freshwater, for pre-filtered tap and well water under 2,000 ppm TDS. Brackish water and seawater 2.5" x 40" elements are sold separately.
  • Packs: Pack of 2 and Pack of 4 contain identical single elements.
  • Not sure? check the part number on your current element (CQE-RC-04109) or contact us. RO membranes are not returnable.
  1. With the system shut down, remove the end caps from the top of the membrane housings (snap ring or clamp bolts, depending on the housing).
  2. Pull the used element out of the top of the housing; heavy-duty or channel-lock pliers may be needed.
  3. Open the new element bag close to the seal, then remove the element and the core tube protectors from each end.
  4. Inspect the brine seal and permeate tube for nicks or cuts, and replace damaged O-rings or brine seals.
  5. Lubricate the brine seal with a food-grade lubricant and install the brine seal end first, following the housing flow direction.
  6. Insert the element at a slight angle with a slow twisting motion so the brine seal stays in its groove, and push it fully into the housing.
  7. Refit the end caps without pinching the O-rings, reinstall the snap ring or clamp, and reconnect any fittings.
  8. Flush the new element for at least 1 hour, discarding all permeate and concentrate, then return the system to service as its manual directs.

Restores production and clean taste in any RO system built for standard 2.5 x 40 inch (2540) membranes, including mid-size Crystal Quest whole house and...

Read more
SKU CQE-RC-04109
Edit selections

Overview

Is your whole house or commercial RO making less water than it used to, or is the product TDS climbing? In a 750 to 2,500 GPD Crystal Quest system, the 2.5" x 40" elements do the purifying. When they tire, the storage tank refills more slowly and the water loses that clean, neutral taste.

The Crystal Quest 2.5" x 40" Freshwater Reverse Osmosis Membrane (CQE-RC-04109, the 2540 element size) is the replacement element listed for the 750, 1,500 and 2,500 GPD Whole House Reverse Osmosis System and the same sizes of the Commercial and Medical Mid-Flow RO Systems. Because 2540 is a standard element size, it also fits other RO systems built for 2.5 x 40 inch membranes. It is a thin-film composite (TFC) element for pre-filtered, dechlorinated tap or well water.

At a glance

  • Counts by system: one for 750 GPD, two for 1,500 GPD, three for 2,500 GPD on the Whole House RO
  • Rated the way engineers compare elements: 99% nominal salt rejection (96% minimum) at 550 ppm, 150 psi, 77°F (25°C) and 15% recovery
  • Freshwater class for feed water under 2,000 ppm TDS; brackish and seawater elements are sold separately
  • Built to last: 2 to 3 years of service; actual life depends on feed water quality, system configuration and usage

What you are looking at

A 40" spiral-wound element. Leaves of TFC membrane, separated by a mesh feed spacer, wrap around a perforated permeate tube that runs the full length. Feed water enters one end and travels along the spacer channels; purified water passes through the membrane and spirals into the center tube, while the concentrate leaves the far end carrying the rejected minerals. The brine seal at the inlet end forces every gallon through the element instead of around it. Each element ships wet in preservative, with core tube protectors on both ends.

How it purifies water

Pressure against osmosis

Dissolved salts create osmotic pressure that pulls water toward the saltier side of a membrane. The system pump overcomes that pull, driving water through the membrane while the dissolved ions stay in the feed stream. Crystal Quest rates these elements at 150 psi operating pressure.

Why there is a drain line

The concentrate stream sweeps the membrane surface clean as it flows, which is how an element runs for years without clogging like a cartridge. A Crystal Quest RO system sends about 1 gallon to drain for every 1 to 3 gallons of purified water, set to your water chemistry. Higher feed TDS calls for a more conservative setting; the manual suggests an auto flush upgrade when feed TDS is above 500 ppm.

Why winter output drops

Cold water moves through the membrane more slowly, and higher TDS raises the osmotic pressure the pump has to beat. The same system can need noticeably more pressure in a cold-water climate to make its rated output, which is why our sizing is based on winter water temperature.

What it reduces

Primary target: dissolved solids (TDS): the hardness minerals, sodium, chloride and sulfate that cause scale, spotting and salty or mineral taste. Crystal Quest whole house RO systems are rated for 96% minimum and 98.5% nominal salt rejection.

Also held back: any particle that reaches the membrane, microplastics included, is far too large to pass. Pre-filters remove most of them first.

Not designed to handle: free chlorine (0.1 ppm maximum, so remove it upstream), sediment, and iron or manganese above 0.05 ppm. Feed hardness for 500 to 2,500 GPD systems should be under 5 gpg; harder water scales the membrane, so soften first. Brackish feed needs the 2.5" x 40" Brackish Water Reverse Osmosis Membrane, and seawater needs the 2.5" x 40" Seawater Desal Reverse Osmosis Membrane.

Why Crystal Quest

  • The listed element and count for your Crystal Quest system, straight from our replacement tables.
  • Complete specs: rejection with test conditions, operating limits and feed water limits in the Specifications tab.
  • Over 1,000,000 people served since 1994. Crystal Quest builds under ISO 9001 quality management, has made water filtration in the USA for over 30 years and offers lifetime support by phone, email or chat.

Where it fits

Once opened or used, RO membranes cannot be returned under our refund policy. Confirm the part number on your current element, or call us and we will confirm it with you.

Standard 2540 format

This is a low-energy freshwater element in the standard 2540 (2.5" x 40") format used in 2.5" x 40" membrane housings and pressure vessels, including Crystal Quest systems. Crystal Quest rates its whole house RO elements at 150 psi operating pressure, well below what brackish water and seawater elements are built for, so the pump does less work on tap and well water. A shared format name is a good start, not a guarantee: if your system is not a Crystal Quest model, compare the brine seal position, permeate tube ends and flow direction with your current element, or contact us before ordering.

Storage and handling

Each element ships sealed in its bag in a preservative solution. Keep it sealed until you are ready to install it, store it indoors out of direct sunlight, and never let it freeze. Once an element has been installed and wetted, do not let it dry out. If your system will sit idle for a season, Membrane Preservative is used to protect the elements against damage from bacterial growth.

Common questions

Which systems use the 2.5" x 40" element?

The 750, 1,500 and 2,500 GPD Whole House Reverse Osmosis System, and the same sizes of the Commercial and Medical Mid-Flow RO Systems.

How many elements do I need?

Use the count in your system's replacement table. On the Whole House Reverse Osmosis System it is one for 750 GPD, two for 1,500 GPD and three for 2,500 GPD.

Should I replace all the elements at once?

Yes. On two- and three-element systems, replacing the full set keeps the elements sharing the load evenly and resets your performance baseline.

How long does a 2540 RO membrane last?

Plan on 2 to 3 years. Actual life depends on feed water quality, system configuration and usage. Good pre-filtration, softening where needed and weekly flushing help it reach the full span.

Why does my system make less water in winter?

Colder water passes through the membrane more slowly. Production returns as the water warms; if it does not, check the pre-filters, then rejection and flow.

Do I need to flush a new element?

Yes. New elements ship in a preservative solution. Flush for at least 1 hour and discard all permeate and concentrate made during the flush.

Freshwater, brackish or seawater?

This is the freshwater element. Crystal Quest also sells 2.5" x 40" brackish water and seawater desal elements. Choose the class your system and feed water are designed for, and ask Crystal Quest if you are unsure.

Specifications

Specifications for your selection

Single

SKU
CQE-RC-04109
Diameter (width)
2.5 in
Length (height)
40.0 in
Replace every
2 to 3 years
Membrane type
Thin-film composite (TFC) reverse osmosis element
Application
Freshwater
Element size
2.5" x 40"
Part number
CQE-RC-04109
Listed replacement for
Whole House Reverse Osmosis System 750 GPD (1), 1,500 GPD (2), 2,500 GPD (3); Commercial and Medical Mid-Flow RO Systems 750 to 2,500 GPD (quantity per system table)
Feed water
Pre-filtered and dechlorinated; free chlorine 0.1 ppm maximum
Rated production
1,000 GPD at 150 psi, 550 ppm feed, 77°F (25°C), 15% recovery; actual output drops with colder or saltier water
Nominal salt rejection
99% (96% minimum) at 550 ppm feed, 150 psi, 77°F (25°C), 15% recovery
Operating pressure
Rated maximum: 600 psi; suggested operating range: 100 to 150 psi
Pressure note
600 psi is the element's structural limit; low energy elements are designed to make their rated flow at about 150 psi
Start-up
Flush at least 1 hour; discard all permeate and concentrate from the flush
Replacement interval
2 to 3 years; actual life depends on feed water quality, system configuration and usage
Format
Standard 2540 element; compare brine seal position and tube ends if your system is not a Crystal Quest model
Storage
Keep sealed until installation, out of direct sunlight; do not let it freeze, and do not let an installed element dry out

Performance curves

Rated 1,000 GPD at 77°F (25°C), 150 psi, 550 ppm feed.

Figure 1. Permeate flow vs feed temperature at 100, 125 and 150 psi, normalized to the rated flow at 77°F (25°C) and 150 psi.
Data for Figure 1
Expected permeate flow in GPD by feed temperature and feed pressure
Feed temperature100 psi125 psi150 psi
40°F (4°C)306389472
50°F (10°C)379482584
60°F (16°C)466592718
70°F (21°C)568721875
77°F (25°C)6498251,000
85°F (29°C)7409391,140
95°F (35°C)8661,1001,330

Values in GPD (gallons per day).

Figure 2. Permeate flow vs feed pressure at 50, 60 and 77°F. Flow follows net driving pressure, the feed pressure minus the feed's osmotic pressure (about 7 psi for the 550 ppm test feed). Shaded: suggested operating range, 100 to 150 psi.
Data for Figure 2
Expected permeate flow in GPD by feed pressure and feed temperature
Feed pressure50°F (10°C)60°F (16°C)77°F (25°C)
25 psi7289123
50 psi175214299
75 psi277340474
100 psi379466649
125 psi482592825
150 psi5847181,000

Values in GPD (gallons per day).

Crystal Quest engineering data. Typical values calculated from the element's rated output at standard test conditions; actual output depends on feed water, recovery and element condition.

Element specifications

Specification Value
Membrane type Thin-film composite (TFC) reverse osmosis element
Application Freshwater
Element size 2.5" x 40"
Part number CQE-RC-04109
Listed replacement for Whole House Reverse Osmosis System 750 GPD (1), 1,500 GPD (2), 2,500 GPD (3); Commercial and Medical Mid-Flow RO Systems 750 to 2,500 GPD (quantity per system table)
Feed water Pre-filtered and dechlorinated; free chlorine 0.1 ppm maximum
Start-up Flush at least 1 hour; discard all permeate and concentrate from the flush
Service life 2 to 3 years*

Element performance

Rated production 1,000 GPD at 150 psi, 550 ppm feed, 77°F (25°C), 15% recovery; actual output drops with colder or saltier water
Nominal salt rejection 99% (96% minimum)
Test conditions 550 ppm feed, 150 psi, 77°F (25°C), 15% recovery
Operating pressure Rated maximum: 600 psi; suggested operating range: 100 to 150 psi
Maximum temperature 113°F (45°C)
pH range Rated 2 to 11; suggested 5 to 11 for continuous operation; cleaning 2 to 12
Free chlorine tolerance 0.1 ppm maximum. Remove chlorine and chloramine before the membrane with carbon pre-filtration (Crystal Quest whole house RO systems include this).
Maximum turbidity 1 NTU
Silt density index Less than 5 SDI

Feed water limits for 500 to 2,500 GPD systems

Total dissolved solids Under 2,000 ppm
Hardness Under 5 gpg
Iron and manganese Under 0.05 ppm each
Silica and organics Under 1 ppm each
Free chlorine None (remove upstream)
Feed temperature 40°F to 105°F

*Service life is an estimate. Actual life depends on feed water quality, system configuration and usage. Performance figures are from the Crystal Quest whole house RO manuals; production falls with colder or higher-TDS water. Element ratings are from the element data sheet. The 600 psi rating is the element's structural limit. Low energy elements are designed to make their rated flow at about 150 psi.

Illustration of a Crystal Quest freshwater reverse osmosis membrane element

Compatibility

Listed as the replacement membrane (CQE-RC-04109) for the 750, 1,500 and 2,500 GPD Crystal Quest Whole House Reverse Osmosis System, which uses one, two and three elements respectively.

The Commercial and Medical Mid-Flow Reverse Osmosis Systems also list this element for their 750, 1,500 and 2,500 GPD sizes. Order the quantity shown in your system's replacement table, and match diameter, length and application class.

Maintenance & care

  • When: plan on every 2 to 3 years; actual life depends on feed water quality, system configuration and usage. Rejection usually holds for two to three years on well pre-treated water, while flow can dip slightly after the first year.
  • Replace the set: on two- and three-element systems, change every element at once so a fresh element is not paired with tired ones.
  • Check it: rejection = (feed TDS minus product TDS) divided by feed TDS. Log it with pressures and flows.
  • Start-up and routine: flush new elements at least 1 hour, discarding permeate and concentrate, then flush the system weekly.
  • Pre-filters: change the sediment and SMART cartridges listed for your size typically every 12 to 24 months, about 18 months for most homes, and yearly on chlorinated city water.

How to replace it

  1. With the system shut down, remove the end caps from the top of the membrane housings (snap ring or clamp bolts, depending on the housing).
  2. Pull the used element out of the top of the housing; heavy-duty or channel-lock pliers may be needed.
  3. Open the new element bag close to the seal, then remove the element and the core tube protectors from each end.
  4. Inspect the brine seal and permeate tube for nicks or cuts, and replace damaged O-rings or brine seals.
  5. Lubricate the brine seal with a food-grade lubricant and install the brine seal end first, following the housing flow direction.
  6. Insert the element at a slight angle with a slow twisting motion so the brine seal stays in its groove, and push it fully into the housing.
  7. Refit the end caps without pinching the O-rings, reinstall the snap ring or clamp, and reconnect any fittings.
  8. Flush the new element for at least 1 hour, discarding all permeate and concentrate, then return the system to service as its manual directs.

Keep output where it should be. Choose Subscribe and Save above for 7% off on the schedule you choose.
