SMART GAC Water Filtration System

SKU: CQE-CO-02059
Regular price $2,656.23
Flow Rate
Control Head
Rendering loop-subscriptions

SMART Commercial Water Filter | Our flagship system for business protection.



Features

  • Timer Control Valves

  • Highest Quality NSF Certified Coconut Shell Granular Activated Carbon

  • Heavy duty composite fiberglass tanks

  • High Flow Distributor

  • All brass, motor driven control valve with fullyadjustable backwash cycles

  • Self-adjusting backwash controller

  • Flow controller to limit backwash flow

  • Engineered for commercial & industrial use

Benefits

  • Reduced water consumption

  • Engineered for commercial & industrial use



Add-Ons*

  • Metered Control Valve

  • Metered to backwash based on demand

  • Backwash bypass

  • 3200NT Controller

  • NXT Upgrade Controller

  • Duplex parallel, twin alternating, triplex (progressive)

  • Optional skid mounting for tanks

*If you are interested in our available add-ons,
please call to have them added to your system.



Manual Filter Valves

  • Multi-port Valve with Filter function

  • Reasonable fluid design

    (Service>Fast Rinse>Backwash>Fast Rinse>Service)

  • Small rotation angle for opening and closing, easy operation

  • Operate under pressure and is leak-proof

  • Manual Filter Valve, Top Mount, 1" In/Out, 1" Female Drain,

    1.05" OD Riser, 2.5" 8-NPSM Connection

  • Manual Filter Valve, Top Mount, 2" In/Out, 1.5" Female Drain,
    1.5" OD Riser, 4" 8-UN Connection

Benefits

  • No electricity and no back wash

  • Both can be up flow or down flow simply by plumbing it backwards.

  • Tank Head, UPVC, 2.5"-8NPSM Opening
    (1" NPT IN/OUT, 1" NPT Center Riser)

  • Tank Head, UPVC, 4"-8UN Opening
    (2" NPT IN/OUT, 1.5" NPT Center Riser)



SMART GAC Water Filtration System reduces & removes harmful contaminants using our special house blend known as SMART Multimedia. These customizable systems come with pre and post-filters and can also be paired with a water softener to take care of any hard water problems.

Crystal Quest® Commercial SMART Filters differ from GAC Filters in that they contain our 2 types of Eagle Redox Alloys® to prevent bacteria growth and extend the life of the Granulated Activated Carbons (GAC). Without our 2 ERA's there is a chance of bacteria growth.

Smart Multimedia filtration is a proven design concept; the coarse media layers in the top of the tank trap large particles, and smaller particles are trapped in the finer layers of media deeper in the filtering bed. The result is highly efficient filtering since removal takes place throughout the entire bed. Smart Multimedia filters typically remove particles 5 to 15 microns in size as opposed to a conventional single media sand filter which will remove 30 microns or higher.

SMART Multimedia has an extended useful life span replacement need varies depending on system size and consumption combined with inflow water conditions the cost of filtration will be less than a penny per gallon!





Service Flow Rate ( GPM)
GPM 15 20 35 60 75 185 200 205
Model No. CQE-CO-02059 CQE-CO-02060 CQE-CO-02061 CQE-CO-02062 CQE-CO-02063 CQE-CO-02064 CQE-CO-02065 CQE-CO-02066
Electronic Control Valve 2510 2815 2815 2900 2900 3900 3900 3900
Pipe Size 1" 1.5" 1.5" 2" 2" 3" 3" 3"
PSI Range 35-60 35-60 35-60 35-60 35-60 35-60 35-60 35-60
Smart Multimedia
3 ft3 4 ft3 7 ft3 10 ft3 15 ft3 20 ft3 30 ft3 40 ft3
Quartz (lbs.) 30 80 100 200 400 500 700 900
Mineral Tank Size (in.) 14x65 16x65 21x62 24x72 30x72 36x72 42x72 48x72
Service flow (gpm) 15 20 35 60 75 185 200 205
Peak flow (gpm) 22 41 60 95 140 250 270 280
Backwash flow (gpm) 5 7 12 15 25 35 50 65
Space Required (in.) (WxDxH) 15x16x75 17x18x75 23x24x84 24x24x95 32x32x95 40x48x95 46x54x95 52x60x95

Consumables
GPM 15 20 35 60 75 185 200 205
Model No. CQE-CO-02059 CQE-CO-02060 CQE-CO-02061 CQE-CO-02062 CQE-CO-02063 CQE-CO-02064 CQE-CO-02065 CQE-CO-02066
Smart Multimedia
3 ft3 4 ft3 7 ft3 10 ft3 15 ft3 20 ft3 30 ft3 40 ft3
Quartz (lbs.) 30 80 100 200 400 500 700 900
